FRAME ASSEMBLY PARTS LIST
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86257776 05120 1 TRANSAXLE, 90VDC .13 HP
- 86216160 140593 - BRUSH SET, TRANSAXLE 05120 CCL SERVICE ONLY
2 86091320 05130 1 ARM, BRUSH HOUSING RIGHT
3 86091330 05131 1 ARM, BRUSH HOUSING LEFT
4 86256050 730175 1 STRAIN RELIEF, 18/3 STR .75
5 86002310 18041 2 CASTER, 4 DIA X 2W X 3.56 R
6 86005680 57047 4 NUT, 1/4-20 HEX NYLOCK
7 86005770 57119 4 NUT, 3/8-16 HEX NYLOCK
8 86249400 62714 2 PLATE, DRIVE AXLE
9 86273780 70015 2 SCR, 1/4-20 X 3/4 HHCS SS
10 86273800 70017 2 SCR, 1/4-20 X 2.50 HHCS SS
11 86006740 70266 12 SCR, 3/8-16 X 1.00 HHCS GR5
12 86008710 80623 4 RING, 3/4 RETAINING HD SH
13 86278910 87003 4 WASHER, 3/8 X 7/8 FLAT SS
14 86279420 87156 4 WASHER, 3/4 X 1.25 NYL
15 86279530 87173 4 WASHER, .77 X 1.31 FLAT SS
16 86259690 89051 4 WHEEL, VAC SHOE
17 86259830 89161 2 WHEEL ASM, CMD20
18 86075960 89137 1 FRAME , WELDMENT
19 86270880 57032 8 NUT, 3/8-16 SERRATED FLG
CMD20 86038150 04/06/07
25
