Windsor Commodore 20 CMD20 User Manual

PUMP ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
27
REF PART NO. PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233150 20042 5 CLAMP,3/8 WORM GEAR
2 86063750 27788 1 COVER, PUMP CMD20
3 86235450 31068 2 ELBOW, 3/8 FPT PVC SCH 80
4 86281150 39282 1 HOSE, 3/8 WIRE BOUND X 7
5 86281680 39486 1 HOSE, 3/8 NYLOBRAID X 2
6 86281780 39502 1 HOSE, 3/8 NYLOBRAID X 33
7 86197510 40010 3 HOSEBARB, 3/8MPT X 3/8
8 86197610 40034 1 HOSEBARB, 3/8MPT X 3/8 90 BRASS
9 86005640 57030 6 NUT, 10-32 HEX NYLOCK
10 86251000 65167 1 PUMP, 115V 100PSI BYPASS
11 86007940 73836 1 STRAINER, DEEP 3/8 NPT 80 MESH
12 86010650 87018 6 WASHER, #10 X 9/16 FLAT
PART NO. PRV NO. DESCRIPTION Parts Included
86026360 65170 PUMP ASSEMBLY, CMD20
(1) 86251000 – PRV NO. 65167 W/MOLEX
CONN.
86136800 73839 SCREEN, 80 MESH STRAINER DEEP
