LIFT LEVER AND LOWER TOWER ASM. PARTS LIST
CMD20 86038150 04/02/07
35
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86228840 09124 2 BEARING, FLANGED .313ID X .052OD
2 86075260 20086 1 CLAMP, CORD
3 86231790 27776 2 CABLE, 25.25 1/4 EYE X 1/4 STUD
4 86238310 36133 1 GRIP, 3/16 X 1.0 FLAT BAR
5 86270770 57006 2 NUT, 1/4-20 HEX
6 86270880 57032 4 NUT, 3/8-16 HEX FLG
7 86005680 57047 3 NUT, 1/4-20 HEX NYLOCK
8 86005750 57113 2 NUT, 5/16-18 HEX NYLOCK
9 86272460 66268 1 PIN, CLEVIS 5/16 X 2.75
10 86273810 70018 1 SCR, 1/4-20 X 1.00 HHCS SS
11 86274350 70187 2 SCR, 10-24 X 1/2 PHTC –F-
12 86006740 70266 4 SCR, 3/8-16 X 1.00 HHCS GR5
13 86274910 70325 2 SCR, 5/16-18 X 1.25 HHCS GR5
14 86008660 80605 1 COTTER, 5/16 RING
15 86010670 87029 1 WASHER, 5/16 X 3/4 SS
16 86279350 87140 2 WASHER, WAVE 1/2 ID X 3/4 D X .125
17 86279580 87183 1 WASHER, 1/2 X 1.00 NYL
18 86095640 89128 1 WELDMENT, POST LOWER CONTROL
19 86259810 89147 2 WHEEL, 2 OD X .31 ID X .88 W PLASTIC
20 86069100 140286 1 BRKT, LIFT LEVER HANDLE
21 86069110 140287 1 BRKT, LIFT LEVER BASE
22 86231210 140317 1 BUSHING, 1.5 HOLE SNAP
23 86279010 87024 8 WASHER, 3/8 STAR
