Windsor Commodore 20 CMD20 User Manual

UPPER TOWER ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
37
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86228860 09128 2 BEARING, 1/4 NYLINER SI
2 86233680 27779 1 COLLAR, .75ODX .281 IDX 1.875
3 86238270 36046 2 GRIP, .8131IDX .085WX13.0L PVC
4 86005680 57047 1 NUT, 1/4-20 HEX NYLCK
5 86005770 57119 2 NUT, 3/8-16 HEX NYLCK
6 86271280 57163 2 NUT, 4-40 HEX W/ STAR
7 86062840 61346 1 PANEL, CMD20 CONTROL
8 86274110 70094 1 SCR, 1/4-20 X 1/2 SHCS
9 86006610 70124 2 SCR, 1/4-20 X 1/4 SSSCU
10 86274350 70187 2 SCR, 10-24 X 1/2 PHTC –F-
11 86275250 70401 2 SCR, 4-40 X 1.25 PPHMS
12 86275860 70554 2 SCR, 3/8-16 X 3.50 HHCS GR5
13 86007160 72157 2 SWITCH, 10A ROLLER MINI
14 86255020 73210 1 SPRING, EXT .36D X 1.5L X .058W
15 86278910 87003 4 WASHER, 3/8 X 7/8 FLAT SS
16 86010640 87016 2 WASHER, #10 EXT STAR SS
17 86092800 89133 1 HANDLE, CMD20 WELDMENT
18 86095680 89138 1 WELDMENT, PROPEL CONTROL
