Windsor Commodore 20 CMD20 User Manual

CONTROL PANEL ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
39
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86230170 14668 1 BREAKER, 8A 250VAC, 50VDC
2 86001980 14700 1 BREAKER, 15A 250VAC, 50VDC
3 86230210 14832 1 BREAKER, 6A VDE
4 86002010 14942 3 BOOT, 3/8 CIRCUIT BREAKER
5 86234310 23675 1 CORD ASM, 13/13 PIGIT X 22 YELLOW
6 86002870 27417 1 CORD, 99807 1/8 X 12
7 86234040 27774 1 CONTROL PROPEL BOARD 115/240V
8 86075520 27795 1 COVER, PROPEL BOARD
9 86242020 48043 1 KNOB, SPEED CONTROL
10 86242920 500234 1 LABEL, CONTROL PANEL P/L
11 86270850 57026 2 NUT, 8-32 HEX NYLCK
12 86005670 57040 1 NUT, 1/2 NPT CONDUIT
13 86005720 57106 2 NUT, 8-32 HEX W/STAR
14 86081010 62666 1 PLATE, CONTROL PANEL
15 86274510 70219 2 SCR, #6 X 1/2 SHT MTL BLK
16 86006870 70406 4 SCR, #10 X 3/8 PHSM TYPE B BLK
17 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER
18 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER
19 86010750 87100 4 WASHER, 3/8 INT STAR
20 86133380 99843 2.8 FT GASKET, 1/8 X 1/2 1SDA FOAM BLK
21 86232320 500235 1 CARD, INTRUCTION P/L
22 86242420 500079 1 LABEL, CIRCUIT BREAKER
23 86245040 50279 1 LABEL, GROUND SYMBOL
24 86264920 27049 1 CABLE TIE 7”
25 86264860 05153 1 ANCHOR , CABLE TIE #8 MOUNT
26 86270920 57049 1 NUT, 6-32 HEX NYLOCK
NOTE: Some items may only be purchased as an assembly.
PLEASE CONTACT YOUR WINDSOR SERVICE REPRESENTATIVE.
