SOLUTION TANK ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
41
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233150 20042 1 CLAMP, 3/8 WORM GEAR
2 86002380 20046 2 CLAMP, 2.25 WORM GEAR
3 86002390 20063 1 CLAMP, 1.75 WORM GEAR X .312
4 86003100 27814 1 CUFF, BLK VAC HOSE
5 86002870 27417 1 CORD, 99807 1/8 X 12
6 86237710 35226 1 GASKET, DOME 9 ID X 30.75 L
7 86004190 39337 1 HOSE, 1.5 BLUE VAC X 24
8 86280990 39239 1 HOSE, 2IN VAC X 20IN
9 86281790 39503 1 HOSE, DRAIN X 44IN
10 86197920 40023 1 HOSEBARB, 1/2MPT X 3/8 NYLON
11 86001530 40039 1 HOSEBARB, 1/2MPT X 1/2 HOSE 90
12 86005100 51296 1 LID, SOLUTION TANK CMD20
13 86258430 53134 1 VAC MOTOR, 115V 5.7 3ST TD TB
14 86005680 57047 4 NUT, 1/4-20 HEX NYLOCK
15 86081130 62691 1 PLATE, CMD20 VAC MTR
16 86033130 62754 1 PLATE, VAC MOTOR COOLING
17 86273810 70018 4 SCR, 1/4-20 X 1.00 HHCS SS
18 86274350 70187 1 SCR, 10-24 X 1/2 PHTC –F-
19 86275180 70375 6 SCR, 5/16-18 X 1/2 HHCS GR5
20 86032200 75243 1 TANK, SOLUTION CMD20
21 86010630 87013 4 WASHER, 1/4 X 5/8 FLAT SS
22 86010640 87016 1 WASHER, #10 EXT STAR SS
23 86010670 87029 6 WASHER, 5/16 X 3/4 SS
24 86279090 87067 6 WASHER, 5/16 INT STAR
SERVICE PARTS
PART NO. PRV NO. DESCRIPTION PARTS INCLUDED
86026870 53787 VAC MOTOR ASSEMBLY, CMD20 86258430 - 53134 (1) W/MOLEX CONN.
86135340 14258 BRUSH SET, 120V 5.7 VAC AMETEK
86135320 140687 BRUSH SET, 120V VAC WINDSOR *
