Windsor Commodore 20 CMD20 User Manual

RECOVERY TANK ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
43
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86073000 14665 1 BRKT, PT17 SIGHT TUBE
2 86002930 27670 1 CORD, DRAIN PLUG
3A 86002400 20064 3 CLAMP, 2.0” WORM GEAR X .312 1000083433
3B 86002350 20002 1 CLAMP, 2.0” NYLON RATCHET
4 - OPEN - -
5 86063730 27765 1 COVER, CMD20 REAR
6 86235270 28057 1 DOME, CMD20
7 86003590 34329 1 FLOAT BALL, VAC SHUT OFF
8 86237650 35219 1 GASKET, 1-1/2 COMPRESSION
9 86237670 35221 1 GASKET, CMD20 DOME
10 86004260 39472 1 HOSE, 1.5 X 24.0 DRAIN
11 86197540 40013 1 HOSEBARB, 3/8MPT X 1/2HOSE
12A 86004510 41391 1 HOSE, INSERT 1000083433
12B 86004450 40019 1 HOSEBARB, 1.5 DOUBLE MCHD
13 86245660 50911 1 LABEL, CMD20 RIGHT
14 86245670 50912 1 LABEL, CMD20 LEFT
15 86005640 57030 4 NUT, 10-32 HEX NYLCK
16 86005660 57033 1 NUT , 1.5 SLIP JOINT
17 86247910 57044 1 NUT, 3/8 NPT HEX BRASS
18A 86004500 41390 1 HOSE,CAP 1000083433
18B 86006240 66227 1 PLUG, DRAIN HOSE
19 86274270 70160 4 SCR, 10-32 X 5/8 PPHMS
20 86274770 70274 6 SCR, 5/16-18 X 3/4 FHMS BLK OX
21 86006750 70302 1 SCR, 5/16-18 X 1.00 HHCS GR5
22 86032210 75244 1 TANK, RECOVERY CMD 20
23 86257860 78390 1 TUBE, 1.5 WASTE
24 86010650 87018 8 WASHER, #10 X 9/16 FLAT
25 86010670 87029 1 WASHER, 5/16 X 3/4 SS
26 86279090 87067 1 WASHER, 5/16 INT STAR
27A 86001370 140408 1 BRKT, HOSE HOOK 1000083433
27B 86001190 140133 1 BRKT, RECOVERY HOSE MTG
28 86003010 27759 1 CUFF, HOSE 1.5” BLK A 2126
29 86240080 39524 1 HOSE, 1.5 BLK VAC X 52”
30 86004970 50990 1 LABEL, WINDSOR LABEL DOMED
SERVICE PARTS LIST
PART NO. PRV NO. DESCRIPTION PARTS INCLUDED
86025180 28059 DOME ASSEMBLY, CMD20
86235270 (1) – PRV NO. 28057
86237670 (1) – PRV NO. 35221
86003590 (1) – PRV NO. 34329
