Windsor EXPERT User Manual

VAC/SOLUTION TANK/CONTROL PANEL PARTS LIST
98363 08/14/07
5-2
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 57104 4 NUT, #10-32 KEPS
2 67029 1 RECTIFIER, BRIDGE
3 14622 1 BREAKER, 1.5A CIRCUIT 10000443236
4 14020 1 TERMINAL BLOCK
5 57116 2 NUT, #6-32 KEPS
6 14700 1 BREAKER, 15A 250 VAC 50 VDC 1000001018
7 87100 1 WASHER, 3/8 INT. LOCK THIN
8 500225 1 LABEL, CIRCUIT BREAKER VAC
9 14942 2 COVER, CIRCUIT BREAKER
10 70595 1 SCREW, 10-32 X 1 PHMS GRN
11 70211 1 SCR, 10-32 X 3/4 PH. BLK NYLON
12 70235 2 SCREW, 6-32 X 1.0 PH BLK NYLON
13 500226 1 LABEL, CIRCUIT BREAKER BRUSH
14 23664 1 CORD ASM, 115V
15 73710 1 STRAIN RELIEF, PG11 METRIC TRUMPET
16 72069 3 SWITCH, 125V DPDT
17 27417 1 CORD, 1/8” X 12”
18 70547 1 SCREW, #10-32 X 1 PPHMS BLK
19 70532 3 SCREW, 10-32 X 1/2 PHMS BLK
20 57208 1 NUT PG11 METAL, 1.024 OD X 0.73 ID
21 27376 3 CLIP, SWITCH RETAINING
22 880041 1 WIRE ASM, PANEL TO BASE
23 20086 1 CLAMP, CORD
24 70222 2 SCR, #8 X ½ PPHST BLK
25 87189 13 WASHER, .2 ID X .5 OD BLK SS
26 70745 11 SCR, #10-5/8 PPHST HI LO BLK
27 27787 1 COVER, REAR (CONTROL PANEL)
28 35182 4 GASKET, FRAME
29 70393 4 SET SCR, 1/4-20 X 1.25L
30 70627 4 SCR, 1/4 X 1/2 PPHST HI-LO
31 20035 1 CLAMP, 7/16 DIA. NYLON UL 1000028686
32 62717 2 PLATE, AXLE EXP
33 34331 1 FRAME/SOL EXP II
34 73864 1 STRAINER, 3/8” NPT 60 MESH
35 35222 1 GASKET, 2 ID X 2.75 X 3/8 THK PORON
36 50746 1 LABEL, WIRING DIAGRAM
37 70517 4 SCREW, 8-32 X 1/2 FHMS SS
38 51254 2 LOCK, HANDLE EXPERT TANK
39 50776 1 LABEL, FOR SAFETY
40 35193 1 GASKET, REAR COVER
41 03102 1 AXLE, WHEEL
42 87146 2 WASHER, 1/2 ID X 1” OD X .08” NYLON
43 89507 2 WHEEL, 8” GREY (HOOSIER)
44 57196 2 HUBCAP, 1/2” DIA
45 53771 1 VAC MOTOR ASM, 115V EXP.
45A 41258 - BRUSH SET, 120V 5.7 VAC, AMETEK SERVICE ONLY
45B 140687 - BRUSH SET, 120V VAC, WINDSOR 1000121568 SERVICE ONLY
46 39276 1 HOSE, 1.5” X 14” VAC
47 27759 1 CUFF, 1.5” BLACK HOSE
48 35169 1 GASKET, VAC COVER
49 27631 1 COVER, VAC MOTOR
50 35175 2 GASKET, TANK TO VAC COVER
51 27632 1 CAP, VAC MOTOR
52 500551 1 LABEL, CONTROL PANEL MAIN
