PUMP ASSEMBLY PARTS LIST
EXP 98363 08/25/04
5-6
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 20016 2 CLAMP, 1/4 ID HOSE
2 39510 1 HOSE, 3/8 WIREBOUND X 3”
3 39468 1 HOSE, 1/4 NYLOBRAID X 11.5”
4 39508 1 HOSE, 1/4 NYLOBRAID X 15”
5 70484 2 SCR, 10-32 X 5/8 PPHMS SS
6 87016 2 WASHER, #10 LOCK EXT. STAR
7 140034 1 BRACKET, PUMP
8 40009 1 HOSEBARB, 1/4 MPT X 1/4
9 40065 1
HOSEBARB, 1/4 MPT X 1/4 X 90°
10 65164 1 PUMP ASM, EXPERT
11 70581 2 SCR, 10-32 X 3/8 HHTFW/WASH
12 78024 1 TEE, 1/4 BRANCH
13 40033 1
HOSEBARB, 1/4 MPT X 3/8 90°
14 20042 1 CLAMP, 3/8 (D-SLOT)
To Next Page
