Windsor EXPERT - Page 21

BRUSH/BRUSH MOTOR/FRAME PARTS LIST
EXP 98363 08/25/04
5-4
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 41279 1 HOUSING, BRUSH W/VAC SHOE
2 27674 1 COVER, ACCESS PORT
3 39276 REF HOSE, 1.5 BLK VAC X 14”
4 35195 1 GASKET, .25 X .75 X 2.00 L
5 27759 1 CUFF, 1.5” BLACK HOSE
6 67138 1 RING, 3/8 EXTERNAL SNAP
7 57104 2 NUT, 10-32 W/STAR WASHER SHOE
8 57030 6 NUT, 10-32 NYLOCK
9 70557 4 SCR, 10-32 X 1” FHMS BLK
10 70532 5 SCR, 10-32 X 1/2 PPHMS BLACK
11 27636 1 COVER, BELT
12 20016 1 CLAMP, 1/4 ID HOSE
13 87139 4 WASHER, 3/16 FLAT
14 09113 1 BEARING, RIGHT
15 70740 3 SCR, 10-32 X 1/2 PTHMS BLK
16 64085 1 PULLEY, MOTOR
17 53608 1 MOTOR ASM, BRUSH DRIVE
18 140036 1 BRACKET ASM, BRUSH MOTOR
19 09114 1 BEARING, LEFT
20 140040 1 BRUSH
21 64086 1 PULLEY, BRUSH
22 11039 1 BELT, BRUSH DRIVE
23 03084 1 AXLE, BRUSH
24 35176 1 GASKET, BOTTOM COVER
25 39468 REF HOSE, ¼ ID NYLOBRD X 11.5”
26 27639 1 COVER, BOTTOM
27 35171 1 GASKET, ACCESS PORT COVER
28 140087 1 BULKHEAD, 1/4 MPT X 1/4 BARB
29 56012 1 NIPPLE, 1/4 FPT QD
30 70303 2 SHOULDER BOLT, 1/4 OD X 5/8 L
31 - - OPEN
32 09117 2 BEARING, BRUSH BRACKET
33 57018 2 NUT, 10-24 HEX LOCK
34 70578 2 SCREW, 8-32 X 1” FHMS SS
35 70031 2 SCR, 10-32 X 1/4 PPHMS
36 87003 1 WASHER, 3/8 ID X 7/8 OD SS
37 62556 1 PLATE, GUARD ON LEFT SIDE ONLY
38 - - OPEN
39 70595 1 SCR, 10-32 X 1.0 PHMS GRN
40 20086 1 CLAMP, CORD
41 73781 4 HOSE, 5/16 X 3/16 ID CLR VINYL
42 70351 4 SCR, 10-32 X 3/8 HHTR W/STAR
43 70604 1 SCR, 10-32 X 5/8 PHMS BLK
44 87189 1 WASHER, .2 ID X .5 OD BLK SS
NOTE: The left and right sides of the machine are assigned as if
standing behind the machine in the operator’s position.
