Windsor EXPERT - Page 29

SOLUTION PLUMBING/SPRAY JET PARTS LIST
EXP 98363 08/25/04
5-12
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 40069 1 HOSEBARB, 3/8 NPT X 3/8 TEE
2 20016 2 CLAMP, 1/4 ID HOSE
3 20042 1 CLAMP, 3/8 HOSE
4 31028 1
ELBOW, 1/8 45° STREET
5 39509 1 HOSE, 3/8” CLEAR X 15.5”
6 62800 1 PLATE, GUARD EXPERT
7 40064 1 HOSE BARB, 1/8” FPT X 1/4”
8 - - OPEN
9 44066 1 JET, BRASS MINI-QUICK
10 44052 1 JET BODY, MINI-QUICK W/SEAL
11 - - OPEN
12 87185 1 WASHER, 3/8 SEALING X 3/4 OD
