TECHNICAL SPECIFICATIONS
86221970 17” SCRUBBER 01/03/07
3-1
ITEM DIMENSION/CAPACITY
Rated Voltage 24 VDC
Rated Amperage 30 Amps
Batteries 2 x 12 Volt 105-130 AH
Scrub Brush Motor 0.75hp (0.56 kw)
Vacuum Motor 24 VDC 2 stage by pass
Mass (GVW) 319 lbs (144.7 kg)
Weight empty without batteries 142 lbs (64.4 kg)
Solution Control Gravity feed, fully variable
Solution tank capacity 8 Gal (30.3 ℓ)
Recovery tank capacity 10 Gal (37.9 ℓ)
Scrub brush diameter 17 in (430 mm)
Scrub brush pressure 33 lbs (15 kg)
Scrub brush speed 200 RPM
Wheels 2 x 6 in (15 cm) Thermoplastic non
marking
Casters 3.0 x 1.0 (75 mm)
Foundation Pressure 286 lbs/in² (1992.6 Kpa)
Coverage 6700 ft²/hr
Frame Construction Steel with epoxy powdercoat finish
Minimum aisle u-turn width 44 in (1110 mm)
Maximum rated climb and descent angle with empty
tanks
2%
Maximum rated climb and descent angle with full tanks 2%
