3
Install the handlebar and re install the clamp to fit the handlebar in place.
Step 3:
Align your handlebars using your 5mm hex wrench. Loosen the two stem bolts using your 5mm
hex wrench and align the handlebars to be perpendicular to the bike frame. Tighten top bolt first, then
the two stem bolts to hold the handlebar position in place.
<- Stem Bolts <- Top Cap
Step 4:
Install front wheel. For this step we recommend turning the bike upside down for ease of
installation. Make sure to align the disc rotor into the brake caliper when installing the wheel onto the
fork. Slide the washers onto the axle outside of fork, and installed before the axle nut, then tighten the
axle nut using the included wrench.
Step 5:
Install seat post. Secure tightly with the hex wrench at the desired height. Do not install
seatpost passed the minimum insert markings.
Step 6:
Install the pedals using the 15mm wrench. Use the pedal marked with an “L” on the left side and
the right pedal marked with an “R” on the right side (side with drivetrain gears).
