4
Be careful to not cross thread the pedals. Pro Tip: Pedal threads always tighten towards the front of the
bike. (Right pedal has clockwise thread/Left pedal has counter clockwise thread). PLEASE NOTE: After
installing the pedals, make sure to also tighten the crank arm bolts with an 8mm hex wrench.
Step 7:
Inflate tires to desired PSI. Recommended pressure 65 PSI for Freedom and Freedom S, 25 PSI
for Freedom Fatty. Do not overinflate or underinflate tires. We recommend checking your tire pressure
once a week. The fender mounts with two small bolts that attach the metal rods to the fork (near the
front wheel axle). The metal tab on the fender itself should sit behind the top of the fork. Insert the
longer bolt through the fork and the metal tab, then add a washer and tighten the nut to secure it.
Step 8:
Hold down the power button on the display on the handlebars to start the bike. Press and hold
the Up Arrow button on the handlebar display to turn the lights on and ensure both lights are activating.
Grab your key fob to test the alarm system. Press the lock button to arm the bike, then move the bike
around to activate the alarm. Once the alarm siren sounds, press the unlock button to disarm, you
should hear 2 beeps when disarming. The middle button on the button pad does not have a function.
Step 9:
Lift rear wheel off the ground and press and hold the down button to ensure the walk assist
spins the motor wheel. WARNING: Do not perform this step unless the rear wheel is off the ground, the
bike will take off if this step is done with the wheel touching the ground.
NOTICE: Ensure all hardware is tightened properly and all safety checks in the following sections are performed before first use.
Contact Wing Bikes if you have any questions regarding the assembly of your bike. If you are not able to ensure all the assembly
steps are performed properly please consult a certified local bicycle service provider for assistance in addition to contacting
Wing Bikes for help.
