Care and Maintenance
17
English
HR 1000
3.
Filter Assembly and Replacement
Filters should be re-installed in the reverse order of their removal.
Insert the replacement
3 Anti-microbial True HEPA filter
(rear)
2 CD Carbon filter (middle)
x
Remove the protective plastic wrap from
new lters. Operating the unit without
removing the protective plastic wrap may
cause abnormal noise, deformation, or re as
a result of overheating.
3 Anti-microbial
True HEPA filter
2 CD Carbon
filter
Insert the 1 Pre-filter
(front).
x
To install the pre-lter, insert bottom tabs
into the slots on either side of the lower part
of the unit, then rotate upward to insert the
upper tabs into the slots at the top part of
the unit until both sides audibly click into
place.
Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until
it magnetically snaps closed.
FILTER CARE
