Winkhaus AV2 / E Manual 8
1
2
3
4
5
6
7
1. To Lock door just ‘slamshut’ (It is not necessary to
lift the handle lever to lock the door as the hooks
throw automatically).
2. Additional security can be achieved by turning the
thumbturn or key. This throws an additional deadbolt
and prevents the hooks being retracted from the
outside if an outside lever has been fitted.*
3. From the inside to open the door pull lever down. This
retracts the hooks and the sprung latch. (If the
deadbolt has not been thrown).*
Outside
4. From the outside access can only be gained via the
key. Turning the key retracts the hooks and the deadbolt
(if thrown).*
Fixed Pad
Inside
Latch
Thumbturn
* AV2/AV2 E also available WITHOUT deadbolt.
