12-7
SECTION 12 –
MISCELLANEOUS
• Maximum Capacity: 225 lbs.
• Do not overload. Ladder is intended for one
person.
• Make sure you are physically capable to
safely use the ladder. Strength, flexibility, and
stability are required.
• Be aware that the vehicle may sway as you
climb the ladder. Do not use the ladder in high
winds.
• As you climb the ladder, grasp the side rails
firmly and always use both hands. Keep your
body centered between the side rails. Do not
over-reach.
• Never allow children on the ladder.
• Do not transport items anchored to the
ladder. You could damage the ladder.
WINDOWS
Horizontal Slider Windows
Lift the Window Latch straight out or up
(depending on the style of window) and slide the
window to the side.
Vertical Slider Windows
Vertical Slider Windows have spring-loaded
catches on both sides of the window that pop out
to hold the window in the fully raised position.
Press the catches outward toward the window
frame to lower the window.
POWER ROOF VENTILATOR
Lounge, Galley, or Bath Area
–If Equipped
The vent dome is raised and lowered using the
Dome Crank knob on the fan.
The turbine fan will start automatically as the
vent is raised, and stop as the vent is lowered.
To Operate Ceiling Ventilator
1. Turn the Dome Crank Knob to raise the dome
about 3" or more to allow the turbine fan to
operate. (A built-in safety switch will not let
the fan motor run unless the dome is partially
open).
WARNING
Do not exceed 225-lb. maximum weight capacity.
Misuse of ladder could result in death or serious injury.
See Operators Manual before using ladder.
Horizontal Slider Window Latches
-Typical View
Vertical Window Catch
(Located on each side of window)
-Typical View
Fan Speed
Selector
Dome Crank
Knob
Power Roof Ventilator
Fuse
To Next Page
