Winnebago Access User Manual

SECTION 8 –
ENTERTAINMENT
8-6
To Play CD Audio (or CD Video)
• The Video Player is also capable of playing
CD Audio music and CD Video discs.
• Insert the CD label side down (facing you)
into the slot on the side of the player. The
player will automatically switch to proper
mode to play audio or video CD.
To Connect Game Systems or
Other A/V Components
• Plug the audio and
video cables of the
game system or
component into the
audio-video input jacks at the rear underside
of the Video Player.
• Switch the game system or component ON.
• Press AV button on Video Player to
select. VIDEO 1 or VIDEO 2 input.
(The component logo or other
indication may appear on screen when
proper input is selected).
• Operate game system or component using the
component’s controller(s).
• See Video Player instruction guide in your
InfoCase for more information.
Reading Lights
• Push the light button to turn the
reading lights on and off.
ELECTRICAL INVERTER
300-Watt DC-to-AC
–If Equipped
The inverter changes 12-volt DC automotive
current into 120-volt AC household current. This
allows you to operate your TV and DVD player
from the house batteries when shoreline hookup
or generator power are not available.* In some
models the inverter is also connected to the 120-
Volt AC outlet for the bedroom TV.
The inverter is typically located in the video
center cabinet or on the lower face of the galley
cabinet.
*NOTE: Running high-amperage appliances
like the TV and DVD on inverter power
can drain the house battery rapidly
unless the chassis engine is running so
the alternator can charge the batteries.
Further Information
See manufacturer’s information provided in
your InfoCase for more information.
TV ANTENNA - DIGITAL
(Jack
®
Digital HDTV Over-the-Air
Antenna)
Your coach is featured with a digital antenna,
which provides crystal clear digital HD reception
of over-the-air channels in addition to superior
broad reception range.
The digital antenna is equipped with a built-in
amplifier for maximum VHF and UHF
programming.
AV
WARNING
Never allow the antenna to touch
electrical power lines or any other
electrical wires.
300-Watt DC-AC Power Inverter
• Turn Inverter On to operate TV.
• Low Battery indicator will light if 12V house
batteries are becoming drained. (Turn Off
inverter to avoid total drain).
• Turn Inverter Off when not in use to avoid
draining house batteries.
• The inverter will shut down when the House/
Coach Battery Disconnect Switch is turned off.
