7-15
SECTION 7 –
PLUMBING
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
24V Waterlines • Two (2) valves beneath shower. Access through
removable panel on lower front of shower cabinet.
• Two (2) valves beneath the bed. Lift mattress to expose
access hole.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in
the city waterline.
Water Tank • One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater • Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• Beneath bed. Lift mattress to expose access hole.
Winterization
(Antifreeze) Valve
• Beneath bed. Lift mattress to expose access hole.
26Q Waterlines • Two (2) valves in galley. Remove bottom drawer under
stove.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in
the city waterline.
Water Tank • One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater • Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• Beneath galley sink. Open doors and remove panel to
access.
Winterization
(Antifreeze) Valve
• Beneath the bed. Lift mattress to expose access hole.
