SECTION 7 –
PLUMBING
7-16
31J Waterlines • Two (2) valves beneath lavatory sink. Access through
removable panel.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in
the city waterline.
Water Tank • One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater • Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• Beneath galley sink. Remove panel to access.
Winterization
(Antifreeze) Valve
• Beneath the bed. Lift mattress to expose access hole.
31R Waterlines • Two (2) valves beneath the bed. Lift mattress to expose
access hole.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in
the city waterline.
Water Tank • One (1) valve beneath the bed. Lift mattress to expose
access hole.
Water Heater • Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve under galley sink behind removable panel.
Winterization
(Antifreeze) Valve
• Beneath bed. Lift mattress to expose access hole.
