9-3
SECTION 9 –
FURNITURE AND SOFTGOODS
• Lift the front edge of the sofa seat upward and
pull outward from the wall while gently
pushing downward on the backrest until the
cushions lie flat.
• The bed is now ready for use.
Bed to Sofa
• Push the front edge of the sofa seat toward the
wall while lifting upward on the backrest until
the sofa is fully seated against the wall and
security latch “clicks” into locked position.
DINETTE/BED CONVERSION
–If Equipped
(Typical view – your coach may differ)
Dinette to Bed
1. Release the catch on the table leg brace and
fold the leg up against the bottom of the table.
2. Remove the table from the wall support
bracket by lifting the end of the table. Then
lower the table to rest on the cleats attached to
each dinette bench.
Security Latch Handle accessible
through front sofa opening
Security Latch Handle
(Shown with sofa seat lifted)
- Press DOWN to release
To Next Page
