10-5
SECTION 10 –
SLIDEOUT ROOMS
There are two slideout motors equipped on the
end wall of each slideout room. Pull back wipe
seal to access motors.
Push-In Procedure
1. Remove slideout motor retention screw
(located along exterior slideout trim), if
equipped.
Repeat on opposite slideout trim.
NOTE: If your coach is not equipped with
slideout motor retention screws, proceed
to Step 2.
2. Pull back wipe seal to access slideout motor.
3. Using a flat-head screwdriver, push bottom of
slideout motor UP to disengage
(approximately 1/2” from base).
Repeat on opposite slideout motor.
4. Push slideout room in to travel position,
ensuring both sides are relatively even.
NOTE: Several people may be needed to push
the room in.
Slideout Motor Retention Screw
(Located along exterior slideout trim)
-If Equipped
Slideout Motor
(Located behind slideout wipe seal)
• Use a screwdriver to push slideout motor
UP (disengage).
• Ensure slideout motor is disengaged
approximately 1/2” from base.
To Next Page
