SECTION 4 –
APPLIANCES AND SYSTEMS
4-4
To Open
1. Push both latches inward to unlock.
2. Remove the door from the opening.
To Close
1. Replace the door into the opening.
2. Push both latches outward to lock.
REFRIGERATOR SERVICE
ACCESS COMPARTMENT
*Model 23T
The refrigerator service compartment (located
on front bedroom wall) allows access to the rear
of the refrigerator for inspection, maintenance,
and service.
To Remove Access Panel
• Use a screwdriver to remove screws around
access panel.
• Remove the access panel from the opening.
• Reverse steps to reattach refrigerator access
panel.
RANGE TOP
–If Equipped
NOTE: See the appliance manufacturer’s user
guide provided in your InfoCase for
complete operating instructions and
safety precautions.
The range in your motorhome operates on
propane gas and will provide most of the
functions of the range in your home.
•Latches
-Typical View
•Latch
Open
•Latch
Closed
Refrigerator Access Panel
(Located on front bedroom wall)
*Model 23T
