SECTION 7 –
PLUMBING
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
Model 23A Waterlines • Two (2) valves accessed behind bottom drawer in
drivers side bed.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve
(small “button” in center of connector) to drain any
water left in the city waterline.
Water Tank • One (1) valve accessed through passenger side
compartment door.
Water Heater • Drain plug on outside of coach behind service door.
Use socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve accessed through passenger side
compartment door.
Model 23T Waterlines • Two (2) valves under dinette seat.
• Two (2) valves under shower. Remove panel to
access.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve
(small “button” in center of connector) to drain any
water left in the city waterline.
Water Tank • One (1) valve beneath galley.
Water Heater • Drain plug on outside of coach behind service door.
Use socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve under dinette seat.
