10-9
SECTION 10
PLUMBING SYSTEMS
10 - PLUMBING SYSTEMS
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
324V (with rear
dinette)
Water Lines:
Water Tank:
Water Heater
By-Pass Valve:
Winterization
(Antifreeze)
Valv e:
Exterior
Shower:
Two (2) valves beneath shower. Access through removable
panel on lower front of shower cabinet.
One (1) valve beneath the dinette cushion along the back-
wall. Lift cushion to expose access hole by bath wall.
Beneath rear dinette. Lift cushion along the sidewall to
expose access hole on front side of dinette.
Located beneath rear dinette. Lift cushion along backwall to
expose access hole by the sidewall.
Lay shower head on ground and open faucet valves to drain
lines and hose.
324F Water Lines:
Water Tank:
Water Heater:
Water Heater
By-Pass Valve:
Winterization
(Antifreeze)
Valv e:
Exterior
Shower:
Two (2) valves beneath galley. Lift bottom shelf to access.
One (1) valve beneath galley. Lift bottom shelf to access.
Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
In bottom of refrigerator cabinet. Remove drawer to access.
Beneath galley. Lift bottom shelf to access.
Lay shower head on ground and open faucet valves to drain
lines and hose.
