SECTION 10
PLUMBING SYSTEMS
10-10
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
327L Water Lines:
Exterior
Shower:
Water Tank:
Water Heater:
Water Heater
By-Pass Valve:
Winterization
(Antifreeze)
Valv e:
Two (2) valves in exterior storage compartment ahead of left
(driver) side rear wheels.
Open exterior shower knobs and lay shower head on ground.
NOTE: If coach is not equipped with exterior shower, there
are two drain valves below the metal face panel on the left
(forward) side of the water center.
Also place the tip of your finger inside the city water con-
nection and gently press the backflow valve (small “button”
in center of connector) to drain any water left in the city
water line.
One (1) valve in exterior storage compartment ahead of left
(driver) side rear wheels.
Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Behind wardrobe cabinet. Remove bottom wardrobe drawer
to access.
In exterior storage compartment ahead of left (driver) side
rear wheels.
329B
329K
Water Lines:
Water Tank:
Water Heater:
Water Heater
By-Pass Valve:
Winterization
(Antifreeze)
Valv e:
Exterior
Shower:
Two (2) valves beneath shower. Access through removable
panel on lower front of shower cabinet.
One (1) valve in drivers side 2nd storage compartment.
In drivers side 2nd storage compartment.
Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
In rear wardrobe. Remove drawer to access.
In driver’s side 2nd storage compartment.
In compartment above driver side rear wheels. Lay shower
head on ground and open faucet valves to drain lines and
hose.
