WATER SYSTEM DRAIN VALVE LOCATIONS
Model System Drain Valve Locations
24G & 24V Waterlines
• Two (2) valves located in water service center.
Water Tank
• One (1) valve located in water service center.
Water Heater
• Drain plug on outside of coach, behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• Model 24G - Located beneath removable access panel under
galley sink cabinet.
• Model 24V - Accessible through backwall compartment door
(remove side panel to access).
Winterization
(Antifreeze) Valve
• Model 24G - Located in water service center
(turn Winterization Valve 2 to “Winterize” position).
• Model 24V - Accessible through backwall compartment door
(remove side panel to access).
