SSD201/202 7-inch Smart Display User manual
8
/14
Wireless-Tag Technology Co., Limited http://www.wireless-tag.com
11
HSD
Horizontal sync input. Negative polarity
12
B7
data bus
13
B6
14
B5
15
B4
16
B3
17
B2
18
B1
19
B0
20
G7
data bus
21
G6
22
G5
23
G4
24
G3
25
G2
26
G1
27
G0
28
R7
data bus
29
R6
30
R5
31
R4
32
R3
33
R2
34
R1
35
R0
36
GND
Ground
37
DCLK
Clock input
38
GND
Ground
39
SHLR
Left or Right Display Control
40
UPDN
Up / Down Display Control
41
VGH
Power supply for Gate on output
42
VGL
Power supply for Gate off output
43
AVDD
Analog Power
44
RSTB
Global reset pin. Active low to enter reset state.
Suggest to connecting with an RC reset circuit for
stability.
