WT32-SC01
10/14
Wireless-Tag Technology Co., Limited http://www.wireless-tag.com
Firmware Burning
1、Step One:
Connect the WT32-SC01 board to the computer via the USB-TypeC data cable. Since
this development board has automatic data flow control processing, the firmware can be
automatically downloaded through ESP32 Flash_Download_Tools.
2
、
Step Two:
As shown in Figure 7-1 below: Select the firmware path to be burned at 1. The address
is usually 0X00. After setting, remember to tick the front; Select the system clock to be
40MHz at 2 locations; Choose the size of Flash as 32Mbit in 3 places; Select SPI MODE as
DIO mode at 4 places; Select the port number of the current board recognized by the
computer at 5; Select the serial port baud rate at 6 places (the larger the value, the faster
the firmware download rate, and the maximum support is 1152000bps); After completing
the previous configuration, click at 7 to start burning the firmware.
3、Step Three:
After completing the above two steps, press the reset button on the back of the
development board to start running the firmware just burned.
