WiseWay GW1949 - Parts List; Warranty and Parts Replacement

21
PARTS LIST
IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS
PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER.
USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.
Key Part
No.
Description Qty.
1 27426 HOPPER LID 1
2 88087 GASKET, WINDOW .125 x 1” w/PSA
3 610201 HOPPER 1
4 610202 PELLET STOP 1
5 83936 1/4-20 PLASTIC KNOB 1
6 610209 HEAT SHIELD
7 27427 FEED LID 1
8 88087 GASKET, WINDOW .125 x 1” w/PSA 3.5 ft
9 27428 PELLET SLIDE 1
10 610192 BURN CHAMBER 1
11 610200 FIREBOX 1
12 610208 WELDMENT, AIR COVER 1
13 610189 HANDLE WELDMENT 3
14 610211 BURN PLATE ASSEMBLY 1
15 610188 ASSEMBLY, ASH PAN 1
16 27452 ASH RETAINER 1
17 83935 TUBE PLUG, SQUARE 4
18 610206 BASE STAND WELDMENT 1
19 610204 DRAFT SLIDE 1
20 892553 GW1949 GLASS 1
21 88087 GASKET, WINDOW .125 x 1” w/PSA
22 610205 WINDOW FRAME 1
23 80653 THERMOMETER, 100-900° STOVE 1
