The following table sums up which parameters can be set and the related range settings.
MENU
PARAMETER
MEANING
RANGE SETTINGS
TUNING
CH
Channel
0 ÷ 59
GR
Group
0 ÷ 39 + SYNC GROUP
Freq
Frequency
depends on the MTP40 Model:
1 470-640
2 566-798
3 510-698
AUDIO
AF In Gain
AF Level
Gain of the audio
signal
-40dB ÷ +40dB step of 1dB
-54dBu ÷ +26dBu step of 1dBu
High Pass Filter
High Pass filter
Flat/60/80/120/170/250/400 Hz
MIC
Phantom (48V)
To enable the
phantom power
supply
On / Off
Phase
Audio signal phase
0° or 180°
Data (TSQ)
To enable the
tone for tone
squelch and
battery data.
On / Off
RF POWER
Power
To enable or not
the RF
transmission
On / Off
Level
RF Power
10mW or 50mW
Autolock
To lock the
transmitter after
the auto turn off
of the display
On / Off
NOISE RED.
Noise Red
Noise reduction
ENR: Wisycom Extended-NR, noise optimized
ENC: Wisycom Extended-NC, voice optimized
LED/BATT
Led Light
Power switch
green brightness
0 ÷ 16
Led Mode
It defines when
the power switch
led (see Fig. 3)
has to become
RED
None: never
ModPeak: when audio get close to saturation
PTT: when the PTT button is pushed
Battery
Battery type
Alkaline, NiMH or Lithium
