<INFO> menu
This menu can be entered by scrolling selector.
In this menu it’s possible to see:
- FW version
- HW version
- Serial number
- Bandwidth
- Bootloader version
- Option
<IRDA> menu
This menu can be entered by pushing .
While there is this menu, the device can be connected to IRDA for
setup or firmware upgrades.
Note: if the IRDA interface is enabled and there’s no communication
for around 10 seconds, the IRDA interface is automatically turned
off.
On power on the device, the IRDA interface is enabled for 14 seconds.
<LOCK> menu
This menu can be entered by pushing .
Long pressing (2 sec.) selector button (SEL) it locks MTB40 in
transmission mode.
To unlock, long pressing (2 sec.) selector button again.
<BOOTLOAD> menu
This menu can be entered pushing at the same time both up and down selector and then pushing the
ON button ( + & ON) or connecting the device via IRDA using the IR Programmer for FW update.
Device is forced in bootloader mode to allow FIRMWARE UPDATE.
