WisyCom MTK982 - TECHNICAL SPECIFICATIONS; Frequency and RF Specifications; Audio and Modulation Specifications; Physical and Power Specifications

MTK982 User Manual
rev.03
18
TECHNICAL SPECIFICATION
Frequency ranges
From 430 to 1260 MHz, depends on the country (see Configurations)
Switchable channels
2400 managed in 40 groups ofr 60 frequencies completely user customizable
Switching-window
330 MHz tuneable
Frequencies
5 kHz steps
RF Power
switchable typ. 10,20,30,50,75,100,150,200,250,400,500,750,1000,1200,1500,2000 mW (ERP)
Max RF output power
2 Watt, RF power can be limited on frequency base accordingly to specific country restrictions
Antenna connector
2 x BNC type female
Auxiliary RF connector
2 x SMA type female
RF impedance
50 Ω
Modulation
FM, MPX Stereo or mono, selectable with dedicated menu
Peak deviation
±56 kHz for mono wideband, ±35 kHz for mono narrowband, ±48 kHz for stereo
(preset mode)
MPX Pilot tone
19kHz
Tone squelch
32.789Hz (for Wisycom wireless microphone, i.e. ENR/ENC)
131,8 (for Wisycom intercom, i.e. NR)
NOTE: custom setting can change the Tone squelch (30-260Hz and 18-38KHz)
Spurious emissions
< 2 nW
Noise Reduction system
ENS , ENC, ENR, NONE-d50, no compander, pre-emphasis 50 μs
NR, to work with Wisycom Intercom system
Other compander on request
AF bandwidth
20÷20kHz (mono)
30÷15kHz (stereo)
NOTE: custom setting can change audio bandwidth (3/4/12/15/20kHz)
Audio input connector
XLR-3 / 1/4“ (6,3mm) jack combo socket, electronically balanced
Audio input level
+18dBu
Pin Assignments
XLR: 1=ground 2=hot 3 =cold
6.35mm (1/4”) TRS: Tip=hot Ring=cold Sleeve=ground
Digital output
AES3 on XLR-3M (32kHz ÷108 kHz)
Monitor output
6.35mm (1/4”) jack socket, balanced
Monitor output level
120+120mW@24Ω , 80+80mW@150Ω
Monitor out impedance
25Ω for auricle
Managing interface
10/100 Base TX Ethernet port on RJ45 connector
Display
64 x 256 OLED (white)
Power supply
90 - 264 V AC, 47/63 Hz
DC options
10-28 Vdc, 6A max
Temperature range
-10 ÷ +55 °C
Dimensions
19”/1U 43,8 x 483 x 349 mm (HxWxD) with brackets
Weight
4 kg approx.
