WisyCom MTP40 - Technical Specifications: Operational Data; Battery Life, Dimensions, and Options

MTP40 User Manual
Rev.04
20
MTP40 Battery
life
(2 AA alkaline)
▪ approx. 10 hours @ 50mW continuous working
▪ approx. 14 hours @ 10mW continuous working
Dimensions
73 x 61 x 17.5 mm (Height-Width-Depth) without clip
Weight
Approx. 80 g. without batteries (120g with batt.)
Note: MTP40 transmitter complies with ETS 300 422
OPTION CODE MTP40-X-YZ :
▪ AUDIO CONNECTOR (-X)
L 3 PIN LEMO CONNECTOR
(use FVB.00.303.NLAE24 with on Mic)
D 2 PIN MICRODOT CONNECTOR
▪ COLOR (-Y)
B body color "matt black"
Ex. MTP40-L-B1 is 3 pins LEMO connector , matt black color and 470-640 Mhz frequency range
▪ FREQUENCY RANGE (-Z)
1 470-640 MHz
2 566-798 MHz
3 510-698 MHz
GND
5.5V
(3 wires)
AF
AF + 5.5V (2 wires)
Option L Lemo Conn.
MTP40
