WisyCom MTP40 - Menu Navigation System; Display Menu Structure Overview

MTP40 User Manual
Rev.04
6
DISPLAY MENU
Setup menu are accessed in sequence:
MENU
STATUS
PRESET
Current
Load from
FACTORY/USER/PRESET1/2/3/4/5/6/7/8
Save to
USER
TUNING
CH 00-59
GR 00-39
Freq
1: 470.000÷640.000
2: 566.000÷798.000
3: 510.000÷698.000
Name
AUDIO
AF In Gain
-20÷40 dsB (1dB step)
HPass Filter
flat/60/80/120/170/250/400Hz
MIC
Mode
2 wires/2wires+bias/3 wires/
2wires&pha/2 w + bias&pha
Phase
0/180
PTT
Disable/Normal/Muting/No Data
RF Power
Power
High/Low
NOISE RED
ENC-Wisy/ENR-Wisy
OTHERS
Led Light 0-16
Led Mode
None/ModPeak/PTT
Battery Alkaline/NiMH
IRDA
Lock
Preset parameters
