The following table sums up which parameters can be set and the related range settings.
MENU
PARAM
ETER
MEANING
RANGE SETTINGS
TUNING
CH
Channel
0 ÷ 59
GR
Group
0 ÷ 39 + SYNC GROUP
Freq
Frequency
depends on the MTP40S Model:
1 470-640
2 566-698
3 510-698
AUDIO
AF In Gain
AF Level
Gain of the audio
signal
-60dB ÷ +40dB step of 1dB
-54dBu ÷ +46dBu step of 1dBu
Phase
Audio signal phase
0° or 180°
HP Filt.
High Pass filter
Flat/60/80/120/170/250/400 Hz
Noise R.
Noise reduction
ENR: Wisycom Extended-NR, noise optimized
ENC: Wisycom Extended-NC, voice optimized
Limiter
Limiter
On/Off
RF/BATTERY
RF Power
RF Power
10mW or 50mW or 100mW (depending on the power
profile)
Battery
Battery type
Alkaline, NiMH or Lithium
LED
Led Light
Power switch green
brightness
0 ÷ 16
Led Mode
It defines when the
power switch led
(see Fig. 3) has to
become RED
None: never
ModPeak: when audio get close to saturation
PTT: when the PTT button is pushed
MIC
Mode
MIC type
’2 wires’
‘2 wires + bias’
‘3 wires’
‘2 wires & phantom’
‘2 wires + bias & phantom’
PTT Mode
It defines how and
what information
the transmitter has
to send
Disable:when the PTT button is pushed, nothing
happen. (the transmitter sends AF+Tone squelch)
Normal: when the PTT button is pushed, the
transmitter send a different RF signal. According to the
receiver configuration the audio can be
enabled/disable on LINE (and/or COM).
Muting: the transmitter doesn’t send the audio. The
voice is cut, it doesn’t enter to the microphone
No Data: the transmitter sends neither tone squelch
nor battery data.
