WisyCom MTP61 - Quick Setup and Operating Menu; Essential Quick Setup Steps; BT Sync Menu Configuration; Preset Menu Management

MTP61 mul-band miniature transmier
5
BTsync
Load
U1‐‐/U2‐‐/DPA….
/Factory
Save U1‐‐/U2‐‐/DPA….
Active Factory/…
Freq Frequency/GR/CH
RFPower
OFF/10/10L/20/20L/50/100mW
Antenna 507/560…
Gain ‐40to+26dB
Ch.Mod. Wide/Narrow
HPF FLAT/45/60/80/120/170/240
MicMode 2W/2W+B/3W/AUX
PTT Disabled/Mute/ON
Phase 0/180
Limiter OFF/ON
Cal.Tone OFF/ON
Frequency 1000Hz/400Hz
Level ‐20dB
REC OFF/ON
Elapsed hh:mm:ss
Remaining hh:mm:ss
Timecode hh:mm:ss
Jam OFF/Running
Source Wire/Tentacle
TC hh:mm:ss
TCext hh:mm:ss
FPS 23.98/24/25/29.97/29.97DF/30/30DF/50/59.94/59.94DF/60
Ubits SMPTE/mm.dd.yy/dd.mm.yy/mm.dd.yyyy/dd.mm.yyyy
Time hh:ss:mm
Date mm:dd:yyyy
BitDepth 24/32bit
Nameby Sequence/Scene&Tk
Scene
1‐99
Shot none/A‐Z
Take 1‐99
Format "warning…"
PRESET
TCsetup
SDCard
RECORDER
CalTone
RF
AUDIO
QUICK SETUP
• connect the microphone to the LEMO 3pin connector
• power on the MTP61
• enable BT sync and syncronize with Wisycom receiver
• connect the correct antenna (see code on RF > Antenna menu)
• set Mic Mode (Audio > Mic Mode menu)
• set the gain, with the maximum input signal, avoiding the peak on the audio bar.
TRY TO SETUP TO HAVE A MAX PEAK HOLD BAR CLOSE TO -6dB.
• configure power level (RF > RF Power)
• jam the TC and activate recording (REC)
OPERATING MENU
