2 Use Instructions with PC
2.1 Connection Method
PC software is only compatible with Windows system.
WT901C Playlist
2.1.1 Serial Connection
Step 1. Connect the sensor with a serial converter
PIN Connection:
VCC - 3.3~5V
TX - Yellow
RX - Green
GND - GND
(When connecting with computer, VCC-5V is recommended.)
