www.wnt.com XND.00004.023_A - 02/2018 24
9 Accessories
9.1 Angle drive
Push in and fix the angle drive as shown in the diagram.
The drive can now be operated with the standard crank.
Lubricate turning parts at regular intervals, e.g. using
MOTOREX Supergliss 68 K lubricant to ISO VG 68.
9.2 Increased clamping range
Fit jaws as shown in the illustration.
Adjust both set screws so that there is no play. (do
not clamp)
10 Taking out of service
The clamping device and all accessories can be disposed of as scrap metal without any risk.
