●Accelerator knob
1、Twist the knob clockwise to increase engine rotate speed.
2、When you shut down engine, twist the knob anticlockwise to
the bottom slowly, decrease engine rotate speed gradually, DO NOT
press the button on top and push knob down to bottom hardly to
avoid knob failure.
3、●Flame out line
Pull up the flame out line to flame out the accelerator.
●Traveling joystick
If you move dozer blade on behind and operate the traveling
joystick, machine will travel to the opposite direction of your
operation. Thus, please confirm the direction of dozer blade
before you travel the machine. Failure on confirmation may
make the machine travel to opposite direction and cause injury
or accident.
When the dozer blade is on front, push traveling joystick forward
will make machine travel forward, pull traveling joystick backward
will make machine
travel backward.
●operation joystick
operation joystick is to
operate boom, arm,
bucket, machine swing or
boom deflection.
