Wolf AHU TE - Internal Unit Connections; Internal Connection Variants

17
3064058_201610
AHU TE
AHUW TE
Installationinstructions
Fixing elements M8 screw
When tightening screws and nuts, always counterhold with
a second open-ended spanner.
Internal appliance connection The individual transport units can always be lifted and transported when units are joined
internally.
Variant1
Variant2
