Wolf AWT - Electrical Connection

7
The electrical connection must only be carriedThe electrical connection must only be carried
The electrical connection must only be carriedThe electrical connection must only be carried
The electrical connection must only be carried
out by a qualified electrician.out by a qualified electrician.
out by a qualified electrician.out by a qualified electrician.
out by a qualified electrician.
Do not route these cables with mains
supply cables.
Electrical connection
Warning
Replace the AWT onto its base and click into
place. When refitting the housing ensure, that
the contact pins on the thermostat are not bent.
AWT terminal strip
Terminal strip
on the gas
fired boiler
5 6
1 2
+ -
Zubehör
+
-
a
b
AF
24VAC 24VDC
ϑ
AWT terminal strip
Terminal strip
on the gas
fired boiler
5 61 2
+ -
Zubehör
!
+
-
a
b
AF
24V
0V
24VDC24VDC
ϑ
AWT terminal
strip
Terminal strip
on the gas
fired boiler
Terminal strip inside the AWT base
3
1526
4
+ -
Plug to the
top part
Telecontrol contact
for eBUS and SCOM
Connection
data cable
e-BUS or SCOM
Connection
of outside
temperature
sensor
- The outside temperature sensor may be
connected either at the gas fired boiler or at
the AWT.
- Install the outside temperature sensor at a
North or North Eastern wall at a height of
2 - 2.5m above the ground (cable grommet
pointing downwards).
- Wire the AWT with 2-core cable (minimum
cross-section 0.5 mm²) in accordance with the
diagram shown.
Wire the AWT with 2-core cable (minimum
cross-section 0.5 mm²) to the gas fired boiler.
Subject to boiler terminal strip, select one of
the adjacent wiring diagrams.
Connection version a)
Connection version b)
Connection version c)
1 2 5 6
+ -
a
b+
A
AF
F
24 V
E1
eBUS
ϑ
Accessory
Accessory
