Wolf CT15G-2 - Orifice Chart (Natural Gas)

GGAASS CCOOOOKKTTOOPP--
GGAASS CCOOOOKKTTOOPP--
22
22
SSEERRIIEESS
SSEERRIIEESS
Technical Data
6-2
GAS PRESSURE
Natural Gas Minimum
Liquid Propane Minimum
Natural Gas and Liquid Propane
Maximum
Gas Supply Line Pressure
Liquid Propane Manifold Pressure, with Standard Orifice
14” WC
Natural Gas Manifold Pressure, with Standard Orifice
7” WC
11” WC
10” WC
5” WC
Description Stamp No. Part No. Elevation In Feet
Valve, Burner, Large
Orifice, Main, Bypass, 61 801326 0 - 10,000
Orifice, Simmer, Bypass, 57 801327 0 - 10,000
Valve, Burner, Small
Orifice, Main, Bypass, 57 801327 0 - 10,000
Orifice, Simmer, Bypass 54 800054 0 - 10,000
Valve, Burner, 15K
Orifice, Main, Bypass, 97 804126 0 - 10,000
Orifice, Simmer, Bypass 62 804128 0 - 10,000
Distribution Ring, Large
Orifice, Simmer M 801329 0 - 10,000
Distribution Ring, Small
Orifice, Simmer J 802947 0 - 10,000
Distribution Ring, 15K
Orifice, Simmer S 804124 0 - 10,000
Jet Holder, Large
Orifice 161 801324 0 - 7,999
Jet Holder, Small
Orifice 140 802325 0 - 7,999
Jet Holder, 15K
Orifice, Main Burner 161 804122 0 - 7,999
ORIFICE CHART
Natural Gas 5” WC
* For Natural Gas Units Installed Over 8,000 Feet, Contact the Factory for High Altitude Conversion Kit.
Figure 6-1. Gas Pressure Chart
Figure 6-2. Natural Gas Orifice Chart
