Wolf CT15G-2 - Orifice Chart (LP)

GGAASS CCOOOOKKTTOOPP--
GGAASS CCOOOOKKTTOOPP--
22
22
SSEERRIIEESS
SSEERRIIEESS
Technical Data
6-3
Description Stamp No. Part No. Elevation In Feet
Valve, Burner Large
Orifice, Main, Bypass 46 800891 0 - 10,000
Orifice, Simmer, Bypass 36 801323 0 - 10,000
Valve, Burner Small
Orifice, Main, Bypass 33 801322 0 - 10,000
Orifice, Simmer, Bypass 37 805645 0 - 10,000
Valve, Burner, 15K
Orifice, Main, Bypass, 60 804127 0 - 10,000
Orifice, Simmer, Bypass 39 804129 0 - 10,000
Distribution Ring, Large
Orifice, Simmer Burner X 801320 0 - 10,000
Distribution Ring, Small
Orifice, Simmer Burner G 805642 0 - 10,000
Distribution Ring, 15K
Orifice, Simmer P 804125 0 - 10,000
Jet Holder, Large
Orifice, Main Burner 104 801318 0 - 10,000
Jet Holder, Small
Orifice, Main Burner 91 801319 0 - 10,000
Jet Holder, 15K
Orifice, Main Burner 115 804123 0 - 10,000
Liquid Propane Gas 10” WC
Figure 6-3. Liquid Propane Gas Orifice Chart
ORIFICE CHART
