L Series Oven Specifications 6
L Series Built-In Ovens
F
or ease of installation, Wolf recommends using 33" (838)
wide cabinets with 30" (762) ovens and 39" (991) wide
cabinets with the 36" (914) L series oven. The installation
opening must have a flat, level base platform to support
the oven. Single ovens require a minimum base support of
250 lbs (113 kg). The double oven requires a minimum
base support of 400 lbs (181 kg).
IMPORTANT NOTE: A minimum 24" (610) of usable
cabinet depth is required or the back panel of the cabinet
may need to be removed for proper installation. The elec-
trical box must be flush with the back panel of the cabinet.
The L series oven is installed by inserting into cabinetry
from the front. The oven has a face trim on all four sides
and will overlap stiles and rails. The trim overlaps
3
/16" (5)
on the top,
1
/8" (3) on the bottom and
3
/4" (19) on each
side.
COMBINATION INSTALLATIONS
Wolf built-in ovens are designed and agency approved for
installation with Wolf cooktops, microwaves and warming
drawers only. The nominal width of the built-in oven
should match the nominal width of the cooktop. A built-in
oven cannot be installed below a Wolf rangetop.
A single oven may be installed next to another L series
single oven. You must allow for a 2
1
/2" (64) space between
the oven rough openings. Also, a separate inner wall is
required for each oven between openings.
