W OLF W ARMING D RAWERS
FRONT PANEL OPTIONS
Model WD30
with Drawer Front Panel Options
Classic Stainless Steel WDFRONT/S
Platinum Stainless Steel WDFRONT/P
Carbon Stainless Steel WDFRONT/B
Integrated
(accepts wood panel) WDFRONT/I
Optional drawer front panels are
ordered and shipped as sales acces-
sories. Stainless steel drawer front
panels include tubular handles.
PLANNING
INFORMATION
The Wolf 30" (762) warming drawer
is shipped without any decorative
drawer front. You must order one of
three stainless steel drawer fronts
(handle included) in classic, platinum
or carbon finish or the integrated
front (no handle) for a custom wood
application.
The illustration below provides the
overall size, while the rough opening
dimensions you will need to incorpo-
rate into your plans are shown in
illustrations on the following pages.
Note that there are significant differ-
ences to the installation requirements
for the integrated drawer front.
An anti-tip block must be installed to
prevent the unit from tipping forward
when the drawer is opened.
A Wolf warming drawer may be
installed below a Wolf single oven
provided the warming drawer is fully
enclosed, top and bottom.
The base platform for the warming
drawer must be able to support 175
lbs (79 kg). This platform must be a
minimum of 1" (25) above the toe
kick to allow for the 1/2" (13) overlap
of the warming drawer trim.
30" (762) Warming Drawer – Overall Dimensions (stainless steel drawer front shown)
The Wolf warming drawer may be
installed below a Wolf electric or gas
cooktop provided the warming
drawer is fully enclosed, top and
bottom. The Wolf warming drawer
may also be installed next to or
above another Wolf warming drawer.
Dimensions will vary according to the
specific installation.
