WOLF INTEGRATED
COOKTOPS
With Wolf's integrated cooktops, you
have the ultimate in customization.
You can create your own design by
mixing and matching the various
components within this system. And
when you couple these modules with
other cooktops within the Wolf
inventory you and your client will
truly understand freedom of choice.
Some modules integrate with their
larger counterparts, right down to
their low-profile grates, dual stacked
gas burners, deep spill pan and
illuminated controls (see important
note below the illustrations). The
two-element electric and dual stacked
burner gas modules deliver the same
performance and appearance as the
larger electric and gas cooktops.
Some integrated cooktops can be
installed together or with a 30" (762)
or 36" (914) cooktop (see important
note below the illustrations). When
multiple units are installed side by
side, the cut-out dimensions that are
shown in the illustration below are
derived by adding 1-1/4" (32) addi-
tional space for each additional unit,
to give you your total cut-out width.
Model IM15/S
Gas Multi-Function
Cooktop
Model IG15/S
Electric Grill Cooktop
Model IS15/S
Electric Steamer Cooktop
Model IF15/S
Electric Fryer Cooktop
W OLF I NTEGRATED C OOKTOPS
When two or more cooktops are
installed together, an integrated
module filler strip (IFILLER/S) is
required. If a downdraft ventilation
system is also installed, an integrated
cooktop support for downdraft venti-
lation (ISUPPORT) is required.
Contact your Wolf dealer for informa-
tion on these accessory components.
IMPORTANT NOTE: Where multiple
units are installed side by side, each
unit must have its own separate
recommended electrical circuit. When
multiple gas units are installed next
to one another, they can receive their
gas supply from a common line.
However, each unit MUST have its
own regulator installed between the
mainline and the integrated cooktop.
IMPORTANT NOTE: Review specific
installation instructions for products
to product capabilities.
Refer to the following illustration for
countertop cut-out dimensions for
installation of multiple cooktops.
2
1
/2"min
(64)
FRONT OF COUNTERTOP
19
1
/4"
(489)
CUT-OUT
DEPTH
29
1
/4" (743)
TWO MODULES WIDTH
44
1
/2" (1130) THREE MODULES WIDTH OR
44
1
/4" (1124) 30" COOKTOP AND ONE MODULE
59
3
/4" (1518) FOUR MODULES WIDTH OR
59
1
/2" (1511) 30" COOKTOP AND TWO MODULES OR
50
1
/4" (1276) 36" COOKTOP AND ONE MODULE
14"
(356)
CUT-OUT
WIDTH
Countertop cut-out dimensions for multiple cooktop installation.
IMPORTANT NOTE: Refer to the
pages for each specific integrated
cooktop model for installation
limitations.
