Wolf MWC24 - Wolf Built-In Ovens

24" (610)
BEHIND FRAME
27
1
/2"
(699)
28
3
/16"
(716)
28"
(711)
29
7
/8"
(759)
24"
(610)
POWER CORD
CHANNEL
OPEN OVEN DOOR
TOP VIEW
26
1
/16"
(662)
3"
(76)
20
3
/4"
(527)
1
1
/4"
(32)
1
7
/8"
(48)
1
7
/8"
(48)
RIGHT SIDE VIEW
24" (610)
BEHIND FRAME
24
3
/8"
(619)
35
5
/8"
(905)
24"
(610)
POWER CORD
CHANNEL
OPEN OVEN DOOR
TOP VIEW
34
1
/8"
(867)
33
11
/16"
(870)
23"
(584)
3"
(76)
17
3
/4"
(451)
1
1
/4"
(32)
1
7
/8"
(48)
1
7
/8"
(48)
RIGHT SIDE VIEW
50"
(1270)
29
7
/8"
(759)
24" (610)
BEHIND FRAME
24"
(610)
OPEN OVEN DOOR
POWER CORD
CHANNEL
TOP VIEW
28
3
/16"
(716)
28"
(711)
3"
(76)
20
3
/4"
(527)
48
1
/2"
(1232)
1
1
/4"
(32)
1
7
/8"
(48)
1
7
/8"
(48)
RIGHT SIDE VIEW
6
W OLF B UILT-IN O VENS
PLANNING
INFORMATION
While you have many design options
to consider from a selection point of
view, there are only three different
sizes to consider when planning for
your layout. You can choose either a
30" (762) or 36" (914) single oven or
a 30" (762) double oven.
Oven Interior Dimensions
• 30" (762) Single Oven:
25"W x 16
1
/4"H x 19"D
(635 x 413 x 483)
• 36" (914) Single Oven:
30"W x 13
1
/4"H x 19"D
(762 x 337 x 483)
• 30" (1524) Double Oven:
25"W x 16
1
/4"H x 19"D
(635 x 413 x 483) each
Space Requirements
The illustrations of the three different
oven sizes give you overall dimen-
sions which include the oven face
trim. Refer to the following pages for
rough opening dimensions and the
installation specifics you will need to
incorporate into your plans.
This appliance must be installed in
accordance with National Electrical
Codes, as well as all state, municipal
and local codes. The correct voltage,
frequency and amperage must be
supplied to the appliance from a
dedicated, grounded circuit that is
protected by a properly sized circuit
breaker or time delay fuse. The
proper voltage, frequency and
amperage ratings are listed on the
model/serial rating plate.
Refer to the installation instructions
shipped with each Wolf product for
detailed specifications.
36" (914) Single Oven – Overall Dimensions
30" (762) Double Oven – Overall Dimensions
30" (762) Single Oven – Overall Dimensions
Dimensions in parentheses are in millimeters unless otherwise specified.
