30" and 36" Cooktop
FLUSH INSTALLATION
WOLF INDUCTION AND ELECTRIC COOKTOPS
A
RECESS
21
1
/8"
(537)
RECESS
1
9
/16" (40) min
W
CUT-OUT WIDTH
COUNTERTOP CUT-OUT
19
1
/2"
(495)
2
1
/2" (64) min
2
1
/2" (64) min
10" (254)
4
1
/2" (114)
E
3
1
/2" (89)
FRONT VIEWSIDE VIEW
NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces,
combustible materials cannot be located within this area.
Electrical supply location only applies to installations with built-in oven.
Inside corner radius
7
/16" (11), outside corner radius 1
5
/16" (33).
30"
(762)
13"
(330)
18"
(457)
2"
(51)
5
/16"
(
8
)
7
/8"
(22) MAX
COUNTERTOP
PROFILE
CUT-OUT WIDTH
MODEL W A
30" Cooktop 28
3
/8" (721) 31
1
/8" (765)
36" Cooktop 34
3
/8" (873) 36
1
/8" (918)
