16
Dimensions in parentheses are in millimeters unless otherwise specified.
25
1
/2"min (648)
ROUGH OPENING DEPTH
WARMING DRAWER
26"min (660)
CABINET DEPTH
*Dimension may vary by
+_
1/8" (3)
NOTE: The width of the custom panel for the warming drawer with integrated drawer front will vary according to the specific installation, but the
rough opening width will remain 29-15/16" (760).
2
3
/8"
(60)
2"(51) x 2"(51)
ANTI-TIP BLOCK
10
3
/8"*
(264)
2
3
/8"
(60)
10
3
/8"*
(264)
CABINET SIDE VIEW
34" (864)
MICROWAVE ROUGH
OPENING WIDTH
24"min
(610)
24
1
/16"
(611)
34
1
/2" (876 )
36-INCH OVEN
ROUGH OPENING WIDTH
5"
(127)
4"
(102)
E
5"
(127)
4"
(102)
E
39"(991)
RECOMMENDED CABINET WIDTH
36"min (914)
1
1
/4"
(32)
20
1
/8"min
(511)
18
11
/16"
(475)
E
5"
(127)
4"
(102)
29
15
/16"* (760)
ROUGH OPENING WIDTH
WARMING DRAWER
Pre-installation specifications for convection microwave with 36" (914) trim – installation
above 36" (914) oven and warming drawer with integrated drawer front.
W OLF C ONVECTION M ICROWAVE O VEN
OPTIONAL
INSTALLATIONS
The following illustrations provide the
finished rough opening dimensions
for installations when combining a
Wolf convection microwave with a
single oven and warming drawer.
The Wolf convection microwave oven
with 30" (762) trim kit may be
installed in combination with a 30"
(762) single oven and 30" (762)
warming drawer with stainless steel
drawer front.
The Wolf convection microwave oven
with 36" (914) trim kit may be
installed in combination with a 36"
(914) single oven and warming
drawer with integrated drawer front.
Keep in mind that the width of the
custom panel for the warming drawer
with integrated drawer front will vary
according to the specific installation.
The rough opening width will remain
29-15/16" (760) whether installed in
combination with a 30" (762) or 36"
(914) single oven and microwave.
IMPORTANT NOTE: A minimum 33"
(838) wide by 26" (660) deep cabinet
is required for the warming drawer
with integrated drawer front.
Refer to the installation instructions
provided with each microwave trim
kit and warming drawer front for
detailed specifications. These instruc-
tions can also be found on the Wolf
website. Dimensions will vary accord-
ing to the specific installation.
28
1
/2" (724)
WARMING DRAWER
ROUGH OPENING WIDTH
28
1
/2" (724)
30-INCH OVEN
ROUGH OPENING WIDTH
5"
(127)
5"
(127)
4"
(102)
4"
(102)
E
E
ALLOW FOR
5
/8" OVERLAP
ON ALL SIDES
9
1
/4" (235)
2
3
/8"
(60)
23
1
/2"min
(597)
2" x 2" ANTI-TIP
BLOCK AGAINST
REAR OF CUT-OUT
27
3
/16"
(691)
1
1
/4"
(32)
24"min
(610)
33" (838)
RECOMMENDED CABINET WIDTH
30"min (762)
28" (711)
MICROWAVE ROUGH
OPENING WIDTH
20
1
/8"min
(511)
18
11
/16"
(475)
5"
(127)
4"
(102)
E
Pre-installation specifications for convection microwave with 30" (762) trim – installation
above 30" (762) oven and 30" (762) warming drawer with stainless steel drawer front.
